If you're looking for specific information about products, pricing, or technical specifications from DH Laser, I recommend visiting their official website or contacting them directly for the most accurate and up-to-date details.
Laser cleaning machine allows for precise removal of materials without damaging the underlying substrate, making it ideal for delicate surfaces.This technology can be applied to a wide range of materials, including metals, plastics, and ceramics.While the initial investment in laser cleaning equipment may be higher, the reduction in labor and materials needed for cleaning can lead to cost savings over time.Many manufacturers, including DH Laser, offer automated and portable solutions, enhancing efficiency and ease of use.
DH Laser is a manufacturer based in China that specializes in advanced laser technology, including pulse laser cleaning systems. These systems utilize high-intensity pulsed lasers to remove contaminants, rust, paint, and other unwanted materials from various surfaces
Number | Name | Technical parameter |
1 | Machine model | DH-C200W |
2 | Output power | 200W |
3 | Laser Source brand | JPT/GZ |
| 4 | Maximum pulse energy | 5MJ |
5 | Laser wave length | 1080nm |
6 | Fiber optical length | 5M |
7 | Capacity control | 1--100% |
8 | Laser cleaning frequency | 1--3000KHZ |
| 9 | Pulse width | 13--500ns |
10 | Cleaning width | 1--100mm |
11 | Cleaning distance | F=200mm |
12 | Working voltage | AC110--220V 50/60HZ |
13 | Attaching plug | European, American, and English standards (customizable) |
14 | Language | China, Britain, South Korea and Russia (customizable) |
15 | Continue working time | 16hours |
16 | Working temperature | -10---40°C |
| 17 | Power Consumptio | ≤ 1KW |
| 18 | Cooling-down method | Air |
19 | Net weight | 20KG |
20 | Package size and weight | 490*210*480mm 38KG |
Product Features
1. The machine shell is made of metal sheet metal by laser cutting, welding and polishing, which is suitable for a variety of harsh working environments and has a beautiful and durable appearance.
2, the whole body metal paint, flat bright surface, bright color, high temperature resistance, corrosion resistance, impact resistance and rubbing resistance, waterproof and oil-proof.
3, metal key start switch and metal power interface, long service life, sensitive response, good contact conductivity, using some harsh working environment.
4. The optical fiber protective sleeve is made of confidential fiber, which is fireproof, waterproof and corrosion-resistant, thus effectively protecting the optical fiber from long-term use in various harsh environments.
5. The laser is made of JPT, a well-known brand in China, with uniform optical mode and stable light output energy. It is designed with flat top light, high energy density of 5MJ and low power consumption for air cooling.
6. The control system adopts high-sensitivity capacitive touch screen, which has fast response speed, 9 kinds of cleaning modes, such as straight line, circle, petal, solid circle filling, horizontal and vertical scanning, etc., and 20 national languages. The interface operation is simple and easy to adjust, and the laser power, frequency, pulse width, graphic size, cleaning speed and reaction time can be adjusted.
7. The weight of the cleaning head is 500g, and the double swing X/Y imported copper wire motor, the lens is made of silicon wafer high temperature Shi Ying material, which does not heat or deform, and the fixed bracket is distributed, which is more convenient for cleaning operation.
1、Pulse fiber laser source 200W
China famous brand laser adopts MOPA flat-topped light design, with stable output energy and uniform optical mode.
2、Control system
Using 7-inch capacitive touch screen and the principle of single chip microcomputer, the laser power, laser frequency, pulse width, cleaning width, filling angle and spacing, 9 cleaning modes and 20 languages can be adjusted.
3、Emergency stop power
Adopt all-metal aluminum alloy aviation socket, which is durable and has stable contact performance.
4、Silent seamless caster
The machine uses four universal casters, which is easy and convenient to push, and the silent design has no noise and drag marks.
5、Start the button
All-metal button material, durable, long life, adapt to a variety of harsh environments, with power identification and LED light display
6、Switching power supply
Choose a switch regulated power supply with stable and reliable performance and long service life, which is well-known in China and suitable for 110--220V voltage.
7、Hand-held cleaning head
All-metal aluminum alloy design, double pendulum imported all-copper motor, Shi Ying lens, fast response, small error, no noise, equipped with special positioning device, more convenient cleaning operation, can also be removed by itself
DH LASER is a leading manufacturer of 200w Laser Cleaning Machines in China. With advanced technology and high-quality materials, our products are efficient and effective for a wide range of cleaning applications. Trust DH LASER for top-of-the-line laser cleaning solutions.
Q: What type of tasks can the 200w Laser Cleaning Machine from DH LASER handle?
A: Our laser cleaning machine is capable of removing rust, paint, oil, and other contaminants from a variety of surfaces including metal, stone, and concrete.
Welcome to DH LASER, the leading manufacturer of 200w laser cleaning machines in China. With years of expertise in laser technology, we specialize in providing high-quality, efficient, and cost-effective laser cleaning solutions for various industries.
At DH LASER, we understand the importance of clean and precise surfaces in manufacturing processes. Our 200w laser cleaning machines are designed to remove rust, paint, oil, and other contaminants from metal, stone, and concrete surfaces with exceptional precision and speed. Our state-of-the-art machines are equipped with advanced laser technology, ensuring minimal material loss and environmental impact.
We are committed to delivering reliable and sustainable solutions to our clients. Our team of experienced engineers and technicians work tirelessly to design and develop innovative laser cleaning machines that meet and exceed our clients' expectations.
Customer satisfaction is at the forefront of our business. We provide comprehensive technical support, training, and after-sales services to ensure that our clients maximize the potential of our laser cleaning machines. Our dedication to quality and customer service has earned us a stellar reputation in the industry.
DH LASER takes pride in being a frontrunner in the laser cleaning machine manufacturing industry. Our commitment to excellence, reliability, and innovation sets us apart from the competition.
Contact us today to learn more about our 200w laser cleaning machines and how they can elevate your manufacturing processes. Join the DH LASER family and experience the power of precision laser cleaning technology.
Take advantage of our unrivaled knowledge and experience, we offer you the best customization service.
Feel free to contact us
Over the years, our products have been exported to the United States, Europe, Southeast Asia, the Middle East and other countries and regions
16 years laser industry application experience,focusing on the research and development and production of laser welding machine, laser cleaning machine, laser marking machine and laser cutting machine.
A cutting-edge innovation from DH LASER, the China 200w Laser Cleaning Machine is a game-changer for industries looking for powerful and efficient cleaning solutions. With its advanced technology, this machine effectively removes rust, paint, and other unwanted coatings without the need for harmful chemicals or manual labor. By investing in this state-of-the-art equipment, businesses can streamline their cleaning processes, increase productivity, and reduce environmental impact. Say goodbye to time-consuming and labor-intensive cleaning methods, and say hello to the future of industrial cleaning. Don't miss out on the opportunity to revolutionize your operations with the China 200w Laser Cleaning Machine.
